How does big players : Azure, Google…

When looking at under the hood architecture for Cloud leaders, we immediately see 2 common things:

  • Few disclosed figures make you feel dizzy (yes, 1 Peta = 1000 Tera…)
  • Very few technical infos disclosed

What happen is that Google & Azure recently let some infos going out for their network 🙂
Facebook is more ahead and provide more information.

Microsoft Azure

About Azure, here are slides from Russinovich master (click on image to get PowerPoint (29 slides)):

2015-06-19_14-37-27

Most important news: they use FPGA (programmable processors) to manage network layer (40GbE/s) (or to mine bitcoins, who knows!).

Last time I had valuable informations was at TechEd in 2012, again from Mark. Video is still online:

  • ~10 people to admin around 100 000 servers!
  • Demo of one of the Azure admin interface,
  • Graphical view of racks with VM,
  • Demo on platform self healing,
  • Explain on leap day bug (29th of february), with even source code line that broke everything

Google

Looks like they index evertything excep their own architecture content (with a killer robots.txt 😉
Techcrunch collected interesting infos, again on their network management (SDN):

http://techcrunch.com/2015/06/17/google-pulls-back-curtain-on-its-data-center-networking-setup/

In 2009, They had published a visite in their datacenter, with a server content inside a container:

2015-06-19_14-56-27

Facebook

They are more chatty, may be frm their DNA…:

https://code.facebook.com/posts/360346274145943/introducing-data-center-fabric-the-next-generation-facebook-data-center-network

Figure 2:

A Facebook server (old model I guess):

Empty at the back is true:

Office365

Most information are about Exchange:

  • Backup less,
  • 3 replicate + 1 Lag at 8 days (goes down to 0 in case of issues)
  • JBOD storage (1 database per hard drive).
  • Optimizations through Exchange 2016

Office 365 is independent from Azure, while some services are using it and merge is upcoming I guess.

Amazon

  • They are using Xen for virtualization,
  • They also make their own server,
  • Based on Open source

Conclusions

They have hyper needs, but also hyper resources to handle them:

  • Complete control of the entire chain: datacenter, network, servers, OS, hypervisor, applications, load balancers, SQL engines
  • Developments in low layers : SDN, FPGA…
  • Source code (and people to handle it): Windows for Microsoft, Linux for Google, Facebook and Amazon
  • They use Open source (OpenFlow, memcache, Hadoop…) but extend them,
  • If they think so, they can spend huge money on topics (like Google with its SDN).

All this gives them a strong independence from other enterprises and their potential buyouts. Other topics may cost less from quantity point of view (ie: earning $50 per server, x300 000)

Where we generally happily stop (geo cluster, DRP, LB) it’s minimum to provide for them. Once this done, another road open with load.
